Features
Specs
Product Line
Features & Benefits
- 2-Way pressure and vacuum test functions
- Intuitive rotary dial mode switch
- Pistol grip with lever
- High volume efficiency in both pressure and vacuum mode
- Manufactured from fiber reinforced composite materials
- Very high strength
- High impact resistance
- Excellent chemical resistance
- Integrated rear mount gauge
- Optimum viewing angle
- Maximum impact protection
- High-quality silicon material hoses with quick couple hose fittings
- Quick hose interchange
- No leaks under vacuum or pressure
- Custom blow mold storage case
- Maximum pressure: 30psi
- Maximum vacuum: 28 in Hg
- Stroke volume: 1 cubic inch (16cc)
- Pump weight: 20.1 ounce
Specifications
- Application: Pressure Mode: Monitor turbo charger boost pressure; Test and adjust turbo charger waste gate actuators; Test pressure operated central locking systems; Test fuel tank vent valves; Test one way valves; Diagnose small engine faults |Vacuum Mode: Test EGR value; Test fuel pressure regulator; Test map sensor; Test thermal and electrical vacuum switches; Test one way valves; Test HVAC valves; Test automatic transmission modulator valve; Test central locking systems
- Brand: MacTools
- Style: Diagnostic
